Automatic Intelligent Rigid Box Making Machine for Boutique Box
LS-900A is a double-positioning fully intelligent automatic box visaul positioning paper gluing machine with high speed and high efficiency, and can poaitinning the top and bottom of the box at the same time. Besides it can also positining double hardcovers at the same time.The machine can make 15-25 pairs of boxes in one minute. The machine has two main parts: double feeder and leaking gluing system, box vision positioning stationQuantity: -
LS-900A
-
Longxingsheng
Machine Introduction:
LS-900A
The speed is fast and the operation is stable. It can make 25 pairs of rigid boxes per minute. The maximum box size can reach 350*250*100mm, and the minimum size can be 80*60*15mm.
This professional-grade machine is designed to streamline and enhance the box-making process. With its advanced features and efficient functionality, it is the perfect solution for both large and small orders.
The main funtion
1. Independent lifting and feeding of double-table boards: (the heights of the two boards are different, but the paper can be fed at the same time during operation, not only can make boxes of different sizes at the same time, but also can make boxes of different heights at the same time, the size of the surface paper is different, the machine will automatically Synchronize to the positioning department to complete the positioning of the box: no company can do this yet)
2. The distance between the two table boards is 4cm: to prevent the staff from accidentally reaching in and pressing their hands
3. A box that can be used as a reverse side fold
4. Two ovens above 100 degrees Celsius, reheat the glue on the surface paper to prevent the glue from drying too fast and causing the glue to not stick well
5. The forming part holds the box separately and operates independently
Experience the convenience and efficiency of the Fully Automatic Intelligent Rigid Box Making Machine. Its professional tone and robust features make it the ideal choice for businesses in need of high-quality box production.
Technical Parameters
Type LS-900A Paper size(max) L650xW400mm Paper size(min) L130xW120mm Max cardboard size / Min cardboard size / Box size(Length) L50-350mm Box size(Width) W50-250mm Box size(Height) H10-120mm Working speed 12-25(Pair)/min Paper thickness 100-350g/m2 Paper stacking height 540mm/100KG Cardboard thickness 0.8-5mm Edge folding size / Turn in depth 15-80mm Motor power 9kw/380V 3phase Machine weight 8kw Air pressure 30L/min Machine dimension L6378xW3860xH2200mm Weight of machine 2300kg production flows:
Machine Features:
1. Paper loading part: Double feeding platform by separated control
2. Feeding system:Automatic cycle feeding by feeder
3. Belt adjustment system: non-stop belt adjustment
4. Gluing system:: Integrated gluing guide groove, easy to clean
5. Paper feeding part: Servo-driven cam feeder effectively avoids double paper feeding.
6.computer control: Servo control digital quick size adjustment
8. Box positioning system: big size range positioning, various in application, single mode running available.
Second pressing to make the bottom of the box stick better
Adopt black and white belt for more color application
Robotic arm: High accuracy ± 0.1mm
Using double cameras to operate independently, high speed and clear photo taking.
Main Parts
1. Double Germany cameras (1000 pixels)2. Mitsubishi servo motor3. Panasonic PLC4. Anti-leaking gluing system5. Servo motor feeding system This professional-grade machine is designed to streamline and enhance the box-making process. With its advanced features and efficient functionality, it is the perfect solution for both large and small orders.
